General Features
DIN Size 2 DIN
Detachable Faceplate No
Disabled System Indicator (DSI) Yes
Security Code Function Yes, set by user
On Screen Display (OSD) Operation Yes
Smooth GUI Yes
Selectable GUI Background Wallpaper Yes
Key Illumination Variable color
Installer Memory Yes
Back-up Memory Yes
Attenuator with Smooth Volume Return Yes
Touch Sensor Tone Yes
IR Remote Sensor Yes
IR Remote Control Yes, included (RC-DV330)
Digital Clock (24H) Yes
ISO connector Yes
Bluetooth unit built-in Yes
Made for iPod Yes
Monitor Features
Display Mode 4 Mode (Full/Just/Zoom/Normal)
Screen Adjustments Brightness/Tint/Colour/Contrast/Black Level/Sharpness/Dimmer
Auto Dimmer manual/navi sync
Visual Source Mode Disc/Ipod/USB/TV/Video1/Video2/AUX
Touch Panel Yes
Mechanism Angle Adjustment 5 Steps + Flat + Reverse Tilt
Reverse Tilt Yes
NTSC/PAL judge Auto

Tuner Features
RDS (PI, PS, AF, TI, Clock) Yes
Radio Text (RDS) Yes
Radio Text Plus Yes
Program Type Function (PTY) Yes
Enhanced Other Networks Function (EON) Yes
K3I - Clean Reception Tuner Yes
FM Reception Yes
AM (MW/LW) Reception Yes
Presets 24 Presets (18FM / 3LW / 3MW)
Station Select List
Automatic Memory Entry (AME) Yes
Up/Down Seek Tuning Yes
Tuning mode (Auto1 / Auto2 / Manual) Yes
FM Stereo / Mono Selector Yes

Audio features
Max. Output Power 4 x 50W
Max. Output Power (MOSFET Power IC) 4 x 30W
Pre-out 4RCA: Front/Rear/Subwoofer/Center
RCA Gold Plated Yes
Pre-out Output Level 5V
Subwoofer Reference Level Adj. Yes
Dual Zone Source & Volume Control Yes
Dual Zone (FRONT / REAR Switchable) Yes
Source Tone Control & Memory By Parametric Equalizer
Balance/Fader Control Yes
Att.(-20dB) with smooth Volume Return Yes
Beep On/Off Yes
Multimedia DSP Features
DSP Chip Freescale
Position Control Yes
Position Preset 3
Position Cabin Size Yes
Graphic equalizer Yes
G-EQ 13 bands
G-EQ KBS Yes
G-EQ manual setting Yes
G-EQ f0 Qty Yes, 4
G-EQ adjustable level Yes, -9dB / +9dB
DRC (Only On Dolby Digital) 3 (Wide/Normal/Midnight)
Time Alignment 0cm ~ 610cm
High Pass Filter Yes (Center)
HPF Cut Off Frequency 7
HPF Cut Slope Level 3
Low Pass Filter Yes (Non-Fading)
LPF Cut Off Frequency 8
LPF Cut Slope Level 3
Cross-over Yes
Source DSP Memory Yes
SRS WOW Yes
WOW 3D Yes
WOW FOCUS Yes
WOW TrueBass Yes
Dolby PrologicII Yes
Dolby Digital Decode Yes
dts decode Yes
Down Mix Control Yes
Speaker Size Control Yes
Channel Level Control Yes
Video Features
Audio/Video Output 1 RCA
Audio/Video Input 2 RCA
Video-In for Rear-view Camera 1 dedicated video input (RCA)
Mirror-mode on Rear-view Image Yes
Detection Mode Rear View Camera Reverse sensor wire
DVD Menu Direct Touch Operation Yes
Dolby Digital Decoder Yes
Dolby Pro Logic II decoder Yes
MPEG Decoder Yes
Linear PCM Decoder Yes
SRS Circle Surround Automotive Decoder Yes
TV ready Yes
Connectivity
External Media Control BUS (KAB) Yes
iPod direct control Yes, with optional KCA-iP301V
USB interface Yes, 2x
SD card slot Yes
OEM Wired Remote Control Yes
Parking sensor wire Yes
Reverse sensor wire Yes
Power Control (P.CON) wire Yes
External Relay Control Yes, 2x
2-way (Tel/Navi) mute wire Yes
Dimmer control wire Yes
TV Tuner Control Yes
Navigation RGB Input Yes
Bluetooth General Features
Hands free Profile (HPF) Yes
Advanced Audio Distribution Profile (A2DP) Yes
Serial Port Profile (SPP) Yes
Headset Profile (HSP) Yes
Phonebook Access Profile (PBAP) Yes
Object Push Profile (OPP) Yes
Synchronization Profile (SYNC) Yes
Audio/Video Remote Control Profile (AVRCP) Yes
Short Message Service (SMS) Yes
Phone device status display Yes
Audio device status display Yes
Signal strength display Yes
Remaining battery display Yes
* depends on phone model/make
Bluetooth SMS features
SMS download Yes
Check received SMS Yes
Check send SMS Yes
SMS receive (Unopened SMS display) Yes
MS sent (Unopened SMS display) Yes
* depends on phone model/make
Bluetooth voice recognition features
Voice tag registration Yes
Voice tag confirmation Yes
Phonebook search by voice tag Yes
* depends on phone model/make
Bluetooth phonebook features
Phonebook download Yes
Phonebook search Yes
Sub index search Yes
Phonebook search by initial Yes
Preset phone number 1 preset x 6 devices
* depends on phone model/make

Accessories
Remote control RC-DV330
IR remote sensor Yes
Battery included Yes, 2 x AAA
Release keys 2 pieces
Escutcheon Yes
Installation Sleeve Yes
DC cord 30 cm
Relay control Cord 2 wires, 50 cm
Microphone with 200 cm cable
General Specifications
Operating voltage 14.4V (10.5 ~ 16V Allowable)
Maximum Current Consumption 15A
Dimensions (WxHxD) 182 x 112 x 163mm
Weight 2.55gr
Operation Temperature Range -10°C ~ 60°C
Storage Temperature Range -20°C ~ 85°C
Instruction Manuals ENG/FRE/GER/DUT/ITA/SPA/POR
Maximum current Relay control wire(s) 500 mA
