800 Watts RMS x 1 Channel @ 4 Ohms

1100 Watts RMS x 1 Channel @ 2 Ohms

1500 Watts RMS x 1 Channel @ 1 Ohm

High Quality FR-4 Circuit Board

Class D Circuitry

Continuously Variable Low-Pass Crossover: 50 - 150 Hz (24 dB/Oct.)

Continuously Variable Subsonic Filter: 15 - 40 Hz (24 dB/Oct.)

Variable Subwoofer Equalizer: 0 - 18 dB

Phase Control: 0° / 180°

Frequency Response: 5 - 250 Hz

Adjustable Input Sensitivity: 0.5 - 4V

Damping Factor: >200

Fully Regulated MOSFET Power Supply

PWM Circuitry

Platinum Power and Ground Connectors

Accepts up to 16VDC Power Input

Wire Bass Remote Included

Dimensions: 15" L x 9-1/2" W x 2-1/2" H

Number of Channels   1 - Mono
RMS Power (4 ohms)   800 watts x 1 chan.
RMS Power (2 ohms)   1100 watts x 1 chan.
RMS Power (1 ohm)   1500 watts x 1 chan.
Bridged RMS Power   Not Bridgeable
Peak Power Output   3000 watts approx.
Min. Impedance Unbridged   1 ohm
Min. Impedance Bridged   Not Bridgeable
THD @ Rated RMS Power   0.5%
Amp Preamp Outputs   Yes - 1 Pair
Built-in Crossover   Yes - LP
Low-Pass Crossover   50 Hz - 150 Hz
Subsonic Filter   15 Hz - 40 Hz
Signal-to-Noise Ratio   80 dB
Bass Boost   0 - 18 dB
