Double DIN størrelse
14 Segment FL Display
50W x 4 Maks effekt

2 RCA linjeutganger

1 RCA Aux-in
WAV, AAC, MP3 & WMA Decoder, 24-Bit Digital Audio Converter
Front AUX Inngang

Blue Illumination + Emotional Illumination Effect

General Features
DIN Size 2 DIN
Faceplate Mechanism Non (Fixed)
Angle Adjustment No
Security Code Function Yes
Key Illumination Selectable: blue, red or green
Rotary Encoder & Control Knob Yes
Operation mode 4-Directions + Push + Rotary
Attenuator with Smooth Volume Return Yes
Touch Sensor Tone Yes
Digital Clock (24H) Yes
All-off Select (20/40/60 minutes) Yes
ISO connector Yes
Display Features
Display Type LCD Display
Display Layout 4 line, Ful dot
Display Illumination blue
Spectrum Analyzer Yes
Dimmer Control 2 steps - Automatic
Auto dimmer control function (on/off) Yes
Positive/negative switchable Yes
Display Off Mode Yes
Demo Mode Yes
Special Character Display No
Tuner Features
RDS (PI, PS, AF, TI, Clock) Yes
Radio Text (RDS) Yes
Program Type Function (PTY) Yes
Enhanced Other Networks Function (EON) Yes
K3I - Clean Reception Tuner Yes
FM Reception Yes
AM (MW/LW) Reception Yes
Presets 24 Presets (18FM / 3LW / 3MW)
Automatic Memory Entry (AME) Yes
Up/Down Seek Tuning Yes
Tuning mode (Auto1 / Auto2 / Manual) Yes
FM Stereo / Mono Selector Yes
CD Features
CD-R/RW Compatible Yes
MP3 Playback with ID3 Tag Display Yes
WMA (Windows Media Audio) Playback Yes
AAC (Advanced Audio Coding) Playback Yes
CD Text Support Yes
Supreme Yes
D.A.C. processing 24 bit (Burr Brown)
0 bit Mute Yes
Random Function (Track/Disc) Yes
Repeat Function (Track/Disc) Yes
Scan Function (Track/Disc) Yes
External Media Control Features
Dual Changer Control (CH1, CH2 & AUX) Yes
CD Text Ready with Compatible KENWOOD Units Yes
Disc & Track Repeat Yes
Disc & Track Scan Yes
Disc & Track Random Play Yes
Direct Access Yes
Disc Name Preset Play (DNPS) Yes
Bluetooth Handsfree Yes
Bluetooth Audio Streaming Yes
iPod Control with KCA-iP500 Yes
Audio Features
Maximum Output Power 50W x 4
MOSFET Power IC Yes
Auxiliary input 1 RCA
Auxiliary input Yes, Front
Auxiliary Type Mini-jack
Pre-out 2 RCA
Pre-out Output Level 2.5V
Preout Rear / Subwoofer Switchable Yes
Subwoofer Reference Level Adj. Yes
Built-In Amplifier Cut-Off Yes
Dual-Zone Source & Volume Control Yes
Dual-Zone (FRONT / REAR Switchable) Yes
Source Tone Control & Memory Bass / Mid / Treble
Balance/Fader/Loudness Control Yes
Att.(-20dB) with smooth Volume Return Yes
System Q_EX (Preset & Manual Sound Control) Yes
System E's+ (Built-in HPF & LPF) Yes
Connectivity
External Media Control Bus (5L) Yes
iPod I/F Control (5L-Bus) Yes
Bluetooth Control (5L-Bus) Yes
PS Amplifier Control System (5L-Bus) PS Amplifiers ('02 - '06)
B.M.S.Control ('99-'03 Amps) Yes
Advanced B.M.S. Control ('02 Amps) Yes
OEM Wired Remote Control Yes
OEM Display Control Yes
Power Control (P.CON) wire Yes
External Amplifier Controle Wire Yes
2-way (Tel/Navi) mute wire Yes
Dimmer control wire Yes
Cosmetics features
Front/edge Black Injection
Dress plate Metalic Black
Volume & operation knob or wheel Chrome Plated
Preset key finish Black Injection
Escution Black Injection
Triangle Illumination Red
Key illumination Selectable: blue, red or green
Illumination Effect Yes
Tuner Specifications
FM Frequency Range 87.5MHz ~ 108MHz
FM Frequency Step 50kHz
FM Usable Sensitivity 0.7μV/75ohm (S/N 26dB)
FM Quieting Sensitivity 1.6μV/75ohm (S/N 46dB)
FM Frequency Response 30Hz ~ 15kHz (± 3dB)
FM Sigal to Noise Ratio 65dB(MONO)
FM Selectivity(DIN) over 80dB (±400kHz)
FM Stereo Separation (1kHz) 35dB
MW Frequency Range 531kHz ~ 1611kHz
MW Frequency step 9kHz
MW Usable Sensitivity 25μV (S/N 20dB)
LW Frequency Range 153kHz ~ 281kHz
LW Usable Sensitivity 45μV (S/N 20dB)
CD Specifications
Laser Diode GaAIAs
Digital Filter(D/A) 8 Times OverSampling
Digital/Analogue Converter 1 Bit
Spindle Speed 500 ~ 200rpm (CLV: 1 times)
Wow & Flutter Below Measurable Limit
Frequency Response 10Hz ~ 20kHz (±1dB)
Total Harmonic Distortion 0.008% (1kHz)
Sigal to Noise Ratio 105dB (1kHz)
Dynamic Range 93dB
MP3 Decoder Compliant with MPEG-1/2 Audio Layer-3
WMA Decoder Compliant with Windows Media Audio
AAC Decoder AAC-LC ".m4a" files
Audio Specifications
Maximum Power 50W x 4
Output Power (DIN45324,+B=14.4v) 22W x 4
Preout Level 2500mV / 10kOhm,
Preout Impedance 600Ohm
Speaker Impedance 4Ohm ~ 8Ohm
AUX Frequency Response 20Hz ~ 20kHz (±1dB)
AUX Maximum Input Voltage 1200mV
AUX Input Impedance 100kOhm
Bass Tone Control 100Hz ±8dB
Middle Tone Control 1kHz ±8dB
Treble Tone Control 10kHz ±8dB
General Specifications
Operating voltage 14.4V (11 ~ 16V Allowable)
Current Consumption 10A
Dimensions (WxHxD) 182 x 112 x 160mm
Weight 1600gr
